Fireproof internal door "EI30 PLUS"

Halspan system EI30 Plus rebated fire door with metal frame equipped with PHA 2000 or PHA 2500 anti-panic hardware and EXACTA 495 ⌀16 mm hinges meet the requirements of PN-EN 1125:2009
in terms of release capability and can be used on escape routes and exits.

The structure of the leaf is a layered particleboard with coniferous wood dovetailed with HDF panels on both sides
Door leaf rebated.

Door leaf thickness: 50 mm.

Frame dimensions:
Max. width “110” – 1212 mm, max. height - 2500 mm

Door coating: Laminates SILKSTONE and LAMISTONE - characterized by an exceptionally beautiful appearance and excellent resistance to minor mechanical damage.

Fire resistance EI230
Smoke tightness: Class Sa, S200
Sound insulation: D1 - 30, D2 - 25, Rw=32 dB
Mechanical strength class 3 according to PN-EN 1192:2001 standard
National Technical Assessment ITB-KOT-2018/0407 issue 2
National Certificate of Constancy of Performance No. 020-UWB-2695/W

Standard equipment:
3 object hinges type OBX by ECO SCHULTE
Mortise lock with cylinder insert
Drop seal

Additional options: Spy-hole

*Additional equipment:
Painted doors by RAL or NCS color pallets; CPL laminate; Veneered
Aluminium decors
Fire resistant grill 300x150mm and 500x150 mm
Electric strikes, electromagnetic locks, reed switch,
additional lock
OBX hinges colour change to black (1 pc)
The leaf can be milled for the installation of an (electronic) hotel lock subject to consultation with the Sales Department.
