Concealed hinge "AGB ECLIPSE 3.2, Black"
Concealed hinge "AGB ECLIPSE 3.2, Black"
Delivery time: 1 - 3 working days
Manufacturer: Alban Giacomo SPA (AGB)
Hinges are designed for flush wooden or aluminum profile doors that can open 180°.
Adjustable in three directions (independently of each other):
Adjustment: vertical +/- 2 mm;
Horizontal +/- 1,5 mm;
Depth +/- 1mm.
Maximum hinge load for doors: with 2 pcs. hinges – 40 kg., 3 pcs. – 60 kg.
Universal use: door opening to the left and right.
Aluminum decorative covers are designed to hide the adjustment screws.
Made of high-quality zinc alloy.
An elegant solution for harmony between the sash and the frame.
Complies with UNI-ISO 2081 standard.
Colors: Black
