Interior doors "NOVA 30" EGGER

DOOR LEAF DIMENSIONS
The door leaf of this model are produced in heights of 1983 mm and 2043 mm, and can be installed in openings with a height of 2006 - 2120 mm.
Height: 198.3 cm; 204.3 cm
Width: 64.4 cm; 74.4 cm; 84.4 cm; 94.4 cm.
Thickness: 4 cm.

ADJUSTABLE FRAME DIMENSIONS
Width: 7.5 - 32 cm. (for walls up to 32 cm thick. For thicker walls, it can be equipped with a frame extension)
Thickness: 2.2 cm

EXTERNAL DIMENSIONS OF THE LEAF WITH ADJUSTABLE FRAME
Height: 205.1 cm. (204.3 cm height door leaf)
Height: 199.1 cm. (198.3 cm height door leaf)
Width: 66.4 cm; 76.4 cm; 86.4 cm; 96.4 cm
*RECOMMENDED HOLE DIMENSIONS:
*Height: min. 206 cm (204.3 cm height door leaf)
*Height: min. 200 cm (198.3 cm height door leaf)
*Width: min. 68 cm; 78 cm; 88 cm; 98 cm

DESCRIPTION OF ARCHITRAVES
Adjustable "L" shaped architraves are made of MDF.
Width: 8 cm.
Thickness: 1.6 cm.

EXTERNALLY ADJUSTABLE FRAME FRAME DIMENSIONS
Height: 212.2 cm (204.3 cm height door leaf)
Height: 206.2 cm (198.3 cm height door leaf)
Width: 78.4 cm; 88.4 cm; 98.4 cm; 108.4 cm.



NON-ADJUSTABLE FRAME DIMENSIONS
Width: 10 cm.
Thickness: 4 cm.

EXTERNAL DIMENSIONS OF LEAF WITH NON-ADJUSTABLE FRAME
Height: 207.3 cm. (204.3 cm height door leaf)
Height: 201.3 cm. (198.3 cm height door leaf)
Width: 68.8 cm; 78.8 cm; 88.8 cm; 98.8 cm.
*RECOMMENDED HOLE DIMENSIONS:
*Height: min. 207.3 cm (204.3 cm height door leaf)
*Height: min. 201.3 cm (198.3 cm height door leaf)
*Width: min. 71 cm; 81 cm; 91 cm; 101 cm

NON-ADJUSTABLE FRAME FRAME DIMENSIONS
Width: 8 cm.
Thickness: 1.6 cm.
